I wrote an example of how to use Terraform with Chef (specifically chef-solo) to provision an environment in AWS EC2. While Terraform does include a built-in Chef provisioner, it requires running the Chef Server. This example instead ships cookbooks to the nodes with the Terraform file provisioning functionality, and uses a simple bash script to install and run chef-solo.

To run the example, you will need an AWS account with API credentials (Access Key ID and Secret Access Key).

git clone git@github.com:mjuuso/provisioning_example.git
cd provisioning_example
./run.sh <aws_access_key> <aws_secret_key>

The script will make sure you have all the prerequisites for running the example (terraform, curl, ssh and ssh-keygen installed), generate SSH keys, run terraform and then verify that the load balancer works as expected.

This will create you the following resources in AWS:

  • two application instances (t2.micro) running a sample Golang application server
  • a load balancer instance (t2.micro) with nginx proxying requests to the application nodes in round-robin fashion
  • an SSH key pair (generated by the wrapper script)
  • two Security Groups -- one for the load balancer, one for the application nodes
  • a Virtual Private Cloud (VPC)
  • two subnets within the VPC, on availability zones eu-west-1a, eu-west-1b
  • an Internet gateway, a routing table and routing table associations

The example could be trivially extended to include a tier of database servers, or even an autoscaling group for the application servers.

For the code, check out https://github.com/mjuuso/provisioning_example.

Find something to improve? Pull requests are very welcome!
