First look at Jenkins 2.0: Building Docker images

For a while now, I've been on the lookout for the best CI/CD automation server that suits our needs in Artirix. We were using ThoughtWorks Go for a while, but found it a bit cumbersome and demanding to maintain. This brought us to the managed ThoughtWorks Snap-CI, which lured us in with a nice interface, cool debugging capabilities (snap-shell) and integration with Github. However, there are a few things in Snap that are starting to hurt us in our daily operations. It has no support for building Docker images (the Docker preview was launched 6 months ago, but they've been quiet ever since), and there's no way for us to easily see what our worker nodes are doing. Trying to run a time-critical manual deployment when (unbeknownst to you) all of your workers are stuck running a 30min test in branch x of repo y is definitely not fun.

With the Jenkins 2.0 beta released last week, I decided to give it a go and set up pipelines for a couple of our apps that are deployed as Docker images. I have to admit, previously I haven't been too much of a Jenkins fan, in part because of the cluttered interface and hacky support for staged pipelines. It seems that 2.0 aims to fix both of these, and it looks very promising.

While it has been available in earlier Jenkins versions, the Pipelines as Code principle is a particularly good step forward promoted by 2.0. Instead of configuring build stages in the tool, they are written in a special Jenkinsfile stored within the repository. Here is a sample Jenkinsfile to build a Docker image:

node {
    stage 'Checkout'
    /* Checkout the code we are currently running against */
    checkout scm

    stage 'Build'
    /* Build the Docker image with a Dockerfile, tagging it with the build number */
    def app = docker.build "artirix/our-app:${env.BUILD_NUMBER}"

    stage 'Test'
    /* We can run tests inside our new image */
    app.inside {
        sh '/app/run_tests.sh'
    }

    stage 'Publish'
    /* Push the image to Docker Hub, using credentials we have setup separately on the worker node */
    app.push 'latest'
}

To use this, you'll need to install the Pipeline and CloudBees Docker Pipeline plugins.

With the new Organization folder type, setup is a breeze. Jenkins traverses a bunch of repos with the Github credentials I gave it, and creates a pipeline on the go for every repo and branch it finds a Jenkinsfile in. As this can be triggered by a webhook from Github, we can have Jenkins create a pipeline on demand for every branch we create - effectively allowing us to run tests for pull requests automatically. This is important for us, and alike what we had setup in Snap-CI.

“Jenkins creates a pipeline on demand for every branch we push to Github.”

Understandably the beta still has a few problems. For some reason I can't seem to save some configuration options for an organization folder, and I was unable to set up a Github webhook to rebuild the organization folder on repository changes. However the new version is definitely a leap forward, making Jenkins 2.0 a very welcome addition to the CI/CD space.
